- Brand Name: Customized
- Min.Order Quantity: No
- Supply Ability: 30~50 thousand ㎡/Month
- Port: Shenzhen
- Service: EMS/OEM/ODM
- Payment Terms: T/T,Paypal,WU etc.
- Layer: 16
- Base Material: High Tg FR4
- Copper Thickness: 1oz
- Board Thickness: 2.43mm
- Solder Mask Color: Green(can customized)
- Silkscreen Color: White(can customized)
- Surface Finishing: Immersion Gold
- Application Industry: Industrial Control
- Application Products: Core board
- Outer Line width/space: 4/4mil
- Inner Line width/space: 3.5/3.5mil
- Min.Hole Size: 0.75mm
- Test Way: 100% E-Test
- Standard: IPC-Class2/Class 3
PRODUCT DETAIL
Our Production Capability for PCB:
| Layer | 1-28 |
| Board finished thickness | 0.21mm-7.0mm |
| Material | FR-4, CEM-1,CEM-3, High TG, FR4 Halogen Free,Rogers |
| Max. finished board size | 23 × 25 ( 580mm×900mm ) |
| Min. drilled hole size | 3mil (0.075mm) |
| Min. Line width | 3mil (0.075mm) |
| Min.Line spacing | 3mil (0.075mm) |
| Surface finish/treatment | HASL / HASL lead free,HAL, Chemical tin,Chemical Gold, Immersion Silver/Gold,OSP,Gold plating |
| Copper thickness | 0.5-7.0 OZ |
| Solder mask color | green/yellow/black/white/red/blue |
| Copper thickness in hole | >25.0 um (>1mil) |
| Inner packing | Vacuum packing / Plastic bag |
| Outer packing | Standard carton packing |
| Shape tolerance | ±0.13 |
| Hole tolerance | PTH: ±0.076 NPTH: ±0.05 |
| Special requirements | Buried and blind vias+controlled impedance +BGA |
| Profiling | Punching, Routing, V-CUT, Beveling |
| Certificate | ROHS, UL, ISO9001-2000, ISO14001 |
| E-Testing | 100% E-Testing (High Voltage Testing); Flying Probe Testing |
| Date file format | GERBER FILE and DRILLING FILE, PROTEL SERIES, PADS2000 SERIES, Powerpcb SERIES, ODB++ |
